Physical Security & VBIED Blast Protection

The following paper was written by Mark Lonsdale while serving as a senior security consultant on a Department of Defense contract at a combined US/Iraqi military base north of Baghdad in early 2004.  This is also the period when the four Blackwater contractors, one a close friend of Lonsdale’s, were killed in Falluja and the Iraqi insurgency began a significant upward surge.

A General Guidance for Military Commanders tasked with Force Protection and FOB Security Operations

By Mark V. Lonsdale

PREFACE

The purpose of this paper is to offer some guidance to military commanders and security managers on how to best protect their bases and facilities from insurgent attack. Keep in mind that security is seldom ideal, and even less so when restricted by budget and the limited availability of resources. Security counter measures can be further compromised by the terrain, the physical limitations of the base or work site, or lack of support at the command or appropriations level.

This paper is not intended as a criticism or even critique of any specific command or location, but merely as an academic discussion of the subject from a tactical perspective.

Mark-Lonsdale Iraq Gen-Paul-Eaton

Mark Lonsdale (left) with General Paul Eaton, Combined Military Assistance Training Team (CMATT) – Iraq 2004

INTRODUCTION

Since the successful terrorist bombing of the US Marine barracks in Beirut (1983) killing over 240 Marines, and then the US Embassy Annex (1984), US military and governmental facilities have come under regular attack by suicide bombers and vehicle-borne improvised explosive devices (VBIEDs). The dramatic destruction of the Oklahoma City Federal Building in 1995 also served to further validate the viability of this form of attack.

In late 2003 and early 2004 these same terrorist tactics and vehicle bombs were used against US and collation bases in Iraq, along with police stations, recruitment centers, civil defense units and NGO facilities. Particularly hard hit was the CPA and checkpoints around the Green Zone; and although these vehicle bombs had not penetrated the outer defenses, they caused significant casualties, disrupted operations, had an adverse affect on morale, and emboldened the anti-coalition forces (ACF) to attempt even more audacious attacks.

As a direct result of these attacks, US military commanders and base security managers were forced to re-evaluate their base security procedures and perimeter defenses. Unfortunately, neither of these subjects had been widely taught within the military system or disseminated in an easy to understand format. Hopefully this paper will help fill some of that void.

However, it must also be understood, and to quote the old adage, “that the best defense is a strong offense.”  For base security this equates to aggressive patrolling outside the wire to deny the enemy access to the perimeter or the opportunity to observe the location and security procedures.

PHYSICAL SECURITY PRINCIPLES

Although actual security counter measures can be quite complex, they generally conform to one or more of the five basic principles of Physical Security.

These are:

  • DETER
  • DENY
  • DETECT
  • DELAY
  • DESTROY

The first principle is to deter an attack by the appearance of a robust security program and substantial physical barriers. Deterrence also comes from an aggressive defensive posture, an alert security force, vehicle checkpoints, vehicles searches, guard towers, lighting, visible weapons positions, and fighting patrols pushing out from the immediate perimeter.

The next principle is to deny access through physical barriers and guard forces. The types of physical barriers include trenches, fences, concertina wire, razor ribbon, Hesco baskets, and Jersey and Alaskan concrete barriers. In the absence of construction resources, a professional guard force can be positioned to deny access. There is however a direct but inverse correlation between physical security and the security guard force. The fewer the physical barriers, the greater the guard force required to secure the same area.

Early detection of an attempted intrusion or breach is critical to an effective fighting response. This is achieved through open ground, standoff, cleared areas, and alert perimeter security personnel. This can be augmented with electronic alarm systems, motion detectors, motion sensitive cameras, guard dogs, trip flares and other noise or light generating devices. At night, the guard force will require either perimeter lighting or NODs to detect an intrusion.

To detect explosive devices or VBIEDs requires a team of specially trained personnel and K-9s certified in IED / explosive identification and detection

When the physical barriers cannot stop an attack, they should at least be positioned to delay the enemy approach. Delay is achieved through the use of physical barriers such as trenches, fences, concertina wire, razor ribbon, Hescos, Jersey barriers or any improvised device that will slow or hinder the enemy’s movement. The delaying barriers should give the guard force the time and opportunity to engage the enemy with effective fire, and for the QRF to reinforce the breach.

Where the Rules of Engagement allow for aggressive counter force, the intent will be to destroy the enemy with whatever weapons are available.

Last “D” is deceased – and that is the end result if fundamental security protocols are not followed. Lives may be needlessly lost for lack of command initiative and/or logistical support.

PERIMETER SECURITY

The three essentials for an effective perimeter system are clear ground, physical barriers and an alert guard force.

Without going into too greater detail, a typical external perimeter for a military or governmental facility would consist of the following physical features with security over-watch.

  1. Clear terrain outside the perimeter to the maximum range possible
  2. Signs outside the perimeter warning the public of the danger of approaching the outer fences and forbidding any form of photography of the installation.
  3. Trenches and/or concertina barbed wire to impede and discourage approach to the outer fence
  4. An outer fence usually constructed of 3- to 4-meter chain-link fence topped with triple strand barbed wire and razor ribbon.
  5. Inner physical barriers such as concrete Jersey Barriers to prevent vehicles crashing through the fence. If a public road passes along the outside of the perimeter fence, then concrete crash barriers should be placed along the shoulder of the road to prevent vehicles veering off the road and into the fence.
  6. Perimeter lighting controlled from the guard towers and/or a central location
  7. An outer perimeter vehicle patrol road just inside the outer fence
  8. Fifty to one hundred meters of clear ground
  9. An inner perimeter fence similar to the outer perimeter fence
  10. Guard towers positioned every 200 meters with mutually supporting over-watch and intersecting fire. Towers should be at least 4 meters high to the floor of the tower and offer adequate protection to the guard force from incoming fire and the elements. Towers should also be connected with either hard-wire comms or RF (VHF) communications.
  11. Running inside the line of towers should be an additional access road and possibly indirect fire / bomb shelters if the threat warrants.

 In general, tower guards, sentries, and soldiers manning checkpoints should be rotated or relieved every four hours. After four hours the level of alertness drops off sharply, particularly in hot climates and inclement weather.

The perimeter security towers and positions should be toured and inspected periodically by officers and senior NCOs during each shift. A Quick Reaction Force (QRF) should be on stand-by for an immediate response to any location on the perimeter.

SECURITY GATES & OPERATIONS

Security gates into high threat areas, or sites the terrorists would consider high value targets, are in fact not a single gate but rather a system of physical barriers and man-power. The three essentials for an effective security gate system are early observation of approaching traffic, approach distance, physical barriers and alert guards.

The guard force must be able to observe the approach of an enemy or vehicle at some distance, in excess of 300 meters, to be able to track and evaluate the vehicles approach and intent. This requires that the gate be sited with consideration to terrain, clear fields of observation, and unobstructed fields of fire.

If a vehicle(s) demonstrates its hostile intent by ignoring warnings or accelerating, then the guard force will have time to take appropriate counter measures. These counter measures will range from securing gates, activating caltrops, to engaging the vehicle and driver with heavy weapons fire (.50 cal, MK 19, M240B, or Sniper).

If the vehicle(s) explodes, it should be at sufficient distance to cause minimal injury or loss of life.

There are a number of physical barriers that can be incorporated into a security gate beginning with some form of obstacle to slow approaching vehicles. The entire security gate operation should also be encircled by some form of security fence, usually 2-3 meter chain-link topped with barbed wire and/or razor ribbon.

Substantial heavy obstacles such as concrete Jersey barriers, sections of large-diameter concrete pipe, or earth filled drums should be used to slow the flow of traffic by being placed in zigzag patterns or chicanes. The spacing on these obstacles will vary depending on the size of vehicles processed through the gate, but in general, a vehicle should be forced to slow to no more than 5 mph (7 kph).

Various forms of tire-shredding devices or caltrops can also be used to deter fast approaching vehicles, and all areas designed to slow vehicles should be covered by at least one and preferably two machinegun (MG) weapons stations.

If drop-bar or swing-bar type security gates are to be used, then a steel cable should be run through the pipe. This can then be secured to a large concrete block of steel pipe set in concrete to make the gate more impenetrable. In the absence of a drop-bar gate, the cable alone can be used as long as it can be securely anchored at both ends.

At the beginning of the approach lane, and at regular intervals down the road, there should be signage in both English and the local language warning drivers and pedestrians of the speed limit and consequences of violating the posted rules. WARNING! SLOW! “Lethal Force is Authorized!”

The most critical component of any security gate operation is the guard force. These need to be alert professional soldiers, MPs or contractors with specialized training in gate operations and security procedures. They also need to be seasoned NCOs with the ability to be polite but assertive when necessary.

Guard posts and guard towers need to be sited so that they can identify approaching vehicles and have early recognition of a threat. This early recognition is critical if they are to have the time to activate counter measures, secure barriers or engage with effective fire.

A running man can cover 50 meters in six or seven seconds, and a vehicle traveling at 30 mph (44 feet per second / 15 meters per second) will cover 100 meters in 6 – 7 seconds. This is very little time for a guard to identify the threat and react to it. This also illustrates the importance of having several hundred meters of visible run-up to any guard gate.

Guard towers should be sited so they have a clear view of the surrounding area and unobstructed fields of fire. Crew-served weapons should also be positioned to over-watch all guard posts, approaches, vehicle check-points (VCP) and search areas. Optimally, two weapons systems should be placed at right-angles with intersecting and supporting fire on areas of high threat such as initial check-points and inspection areas.  Approaching drivers should feel intimidated by the firepower that can be brought into play if required.

In addition to suitable weapons systems, the guards in the guard towers and fixed positions should be issued range cards that give pre-measured distances to all visible landmarks. They should also be given the opportunity to test fire and zero their weapons under realistic range conditions that replicate the security towers.

At night the guard towers should be equipped with night observation devices (NODs) and weapons should have night weapons sights. As with iron sights and day-optics, it is essential that the night sights have also been zeroed to the weapons system.

VEHICLE BORNE IMPROVISED EXPLOSIVE DEVICES – VBIEDs

Car and Truck bombs (VBIEDs) have posed a significant threat to the US military since the bombing of the Marine Barracks in Beirut. They have also been successfully employed against targets such as the Oklahoma City Federal Building, the World Trade Center (1993), and more recently Kobar Towers.

Since deploying to Iraq in support of Operations Iraqi Freedom, VBIEDs have been successfully used against the entrances to the Green Zone, various police and military installations, government buildings, and most US military bases.

The obvious danger with VBIEDs is that they carry significant amounts of explosive ranging from 100 to 2,000 pounds, and that stopping a fast moving vehicle before it penetrates the security cordon is no easy matter.

The two primary types of explosive devices built into vehicles are military munitions and homemade explosives. The military munitions often consist of assorted 155mm artillery shells or mortar bombs primed with some form of C-4 or Semtex-type plastic explosive. This type of device may create a smaller blast since the over all explosive weight is smaller, but the high velocity fragmentation from the shell casings is deadly.

The non-military ordnance and home-made devices are often composed of some form of “fertilizer bomb” utilizing ammonium nitrate and fuel oil (AMFO). These are cheap to make and have already been found in Iraq in 300 to 500 pound devices. These large devices derive their devastating power from the fact that AMFO is a slower velocity explosive but generates incredible pushing power. Unlike military explosives which have high brisance and dissipate energy quickly, fertilizer bombs are similar to those used in quarrying and designed to move large amounts of earth. The shockwave will travel further and cause significant structural damage, so counter measures and blast barriers must be proportionately more robust.

There are a number of forces at play with a VBIED, most of which are quite deadly. The first is the initial blast and resulting shock wave that can knock down structures and cause massive overpressure injuries. Accompanying the blast wave is the high velocity primary fragmentation either from the device itself or shrapnel packed around the device.

A blast will also create secondary fragmentation from any of the surrounding structures to include concrete, glass, metal and rocks. The next concern is fall-out and fragmentation from the explosion that will be returning to earth at terminal velocity for several seconds after the initial blast. This necessitates overhead protection for the guard force.

Finally there are the risks of sympathetic detonation of surrounding vehicles as their gas tanks ignite; ammunition cooking off in damaged military vehicles; additional flammable substances that may be on trucks in the vicinity; or ammunition storage points or fuel farms that may have been the primary target of the attack.

When dealing with VBIEDs, the first security principal is to get the vehicle slowed down and stopped some distance from the initial US military checkpoint. The aim is to create as much distance as possible between a potential explosion and the US or coalition forces. If the driver becomes nervous and blows his load, then the loss of life should be limited to the two to four soldiers or local police at the initial checkpoint. A brutal but sad reality.

There should be at least three to four vehicle stops or checkpoints within the security system:

  1. Initial ID check to make sure the car or truck is supposed to be entering the camp and the driver is who he says he is.
  2. Vehicle search by Iraqi soldiers, police or civil defense
  3. Vehicle search by US or coalition soldiers or security contractors
  4. Detailed inspection of the vehicle’s load if required.

Explosives trained K-9s should be utilized during the first or second phases of the search process, but unfortunately, since the K-9 handlers are usually US soldiers or contract force protection specialist, the K-9s are not utilized until the vehicle has reached the third or forth checkpoint within the security zone.

If the suicide driver makes the decision to run the checkpoint with the hope of causing greater destruction, then the physical barriers should be sufficient to stop the vehicle; guards should have the time and appropriate weapons systems to engage the vehicle and driver with effective fire; and the surrounding berms, Hescos, Jersy and Alaskan barriers (T walls) should contain the blast resulting in minimal damage or loss of life.

GUARD FORCE TRAINING

Although alert and professional, US soldiers and Marines do not receive formal training in security gate operations during their basic training.

Programs need to be instituted to give soldiers the basic procedures for security gate operations, vehicle search procedure, ID check procedures, checkpoint interview techniques, IED identification, reaction to suspicious vehicles or individuals, tower operations, rules of engagement, and post-blast reaction drills.

This type of training can be coordinated through the Military Police, S-2 shop, Air Force force-protection instructors, or civilian contractors.

CONCLUSION

There are two factors that continue to create significant weakness in perimeter and gate security operations – flow rate and training. International airports are a good example of these problems that almost everyone has seen and experienced.

First, the airport must process high volumes of passengers and baggage in a timely manner. For example, 400 individuals, 800 pieces of hull baggage, and an equal number of carry-on pieces need to be processed for each international 747 flight in less than two hours.

Similarly, on a military base or FOB, 2,000 – 4,000 visitors and workers must be processed each day, along with several hundred non-military vehicles.

The sheer volume that must be processed precludes any expectations of a detailed search of all vehicles, or computer database background review of drivers and visiting individuals.

The second problem is the lack of a professionally trained guard force. The slovenly minimum wage security worker has become an all too familiar sight at US airports, and while our soldiers have a professional appearance, they have not received intense training in security operations, IED identification, terrorist methodology, smuggling and concealment methods, or individual interview and vetting.

These two issues – flow rate and lack of training – create significant opportunities for terrorists to capitalize on the weakness in base defenses.

Finally, and on a more military level, a base will always be vulnerable to attack if the area around the base is not heavily patrolled. Fighting patrols need to be operating 24/7 out to the maximum range of the enemy’s weapons – for example, 3,000 – 5,000 meters for indirect fire weapons such as the mortar.

These patrols need to be augmented with HUMINT collection efforts, covert OPs, sniper operations, night ambushes, and surprise vehicle checkpoints. In this manner, and with this level of aggressive counter measures, the terrorists and insurgents will be forced to move on up the road to softer targets.

Copyright © 2007/2017

Mark Lonsdale Iraq 2004

Mark Lonsdale doing a bomb damage assessment after a rocket strike at Taji Military Base in Iraq – 2004

END

For military and security advisory services, Mark Lonsdale can be contacted directly at STTUOperations@gmail.com

Posted in Uncategorized | Leave a comment

Armed Contractors in the Battle Space

The following paper was written for a December 2006 conference at the US Army War College hosted by the Peacekeeping and Stability Operations Institute (PKSOI), and later published in the October 2007 issue of the IPOA journal. The purpose of this paper was to introduce the position of DoD security contractors as stakeholders in US military Phase IV stability operations.



By Mark V. Lonsdale

As evidenced by the types of contracts being funded and awarded by DOD in Iraq and Afghanistan, many mission critical services are being outsourced to civilian contractors. These essential security, stabilization, reconstruction (S&R), and security sector reform (SSR) services were traditionally handled by the military but with the current lean force structure of the US military, and its primary focus on those tasks directly related to warfighting, the civilian contractor has become an essential component of Phase IV operations.

Mark Lonsdale Kandahar Aghanistan 2008

Mark Lonsdale – Kandahar, Afghanistan 2008

Private security companies (PSC) are being tasked as convoy escort teams (CET), protective security details (PSD), close protection (CP) for key commanders and political figures, static security for military and governmental installations, mine and ordnance clearance, police and military mentoring and training, and intelligence collection, collation and distribution as it pertains to the above operations.

Historically it was envisioned that these functions would be handled in a post-conflict permissive environment, but the ongoing operations in Iraq and Afghanistan have necessitated that security contractors up-armor and up-gun to be able to operate alongside the military in the battle space.

This has created a situation where combatant commanders and US troops are required to interface with armed contractors on a daily basis. Unfortunately there are very few mechanisms in place that facilitate this relationship between the military and the security providers. Ground commanders are confronted with such issues as:

  1. Where do these contractors fall into the chain of command?
  2. How do they communicate with them?
  3. How do they track their movements?
    1. Contractors do not show up on the Blue Force Tracker system
    2. TOCs are not always notified of CET and PSD movements
    3. Commanders are not notified when a CET or PSD is operating in their AOR so have problems mounting QRFs or CASEVACs
  4. What are the SOPs and ROE for contractors?
  5. Are the weapons they are carrying authorized?
  6. There are no standardized uniforms, vehicles, or visual recognition signals – some contractors looking like something out of “Mad Max”
  7. How are injured international contractors to be handled? Particularly third country nationals (TCNs) and local nationals (LN)
  8. The use of armed Iraqis as security guards has created operational security issues for FOB commanders.

The security contractors also have their share of problems and issues. PSCs have complained of:

  1. Being fired upon by US military convoys (Blue on White incidents)
  2. Being fired upon by soldiers manning vehicle check points (VCP)
  3. Lack of recognition of their visual signals (US flags; Union Jack; VS-17 panels)
  4. Lack of recognition of their identification cards – particularly non-DOD ID cards such as MNF-I cards.
  5. Being detained for hours at check points where junior enlisted personnel had not been briefed on the presence of armed contractors in the AO.
  6. Being unable to contact the TOCs for the AOs they move through on a daily basis
  7. Lack of access to military bases for security personnel injured by IEDs or SAF.
  8. Mortuary services
  9. etc

Many of these problems can be traced back to the shortfalls in DOD’s formal plans for the execution of Phase IV operations. The role of PSCs and armed contractors operating in the battle space has not been written into doctrine, training or plans so it is no surprise that combatant commanders and ground troops are unclear as to the handling, SOPs and ROEs for these contractors.

DOD, as the source of funds and contracts, is in the position to dictate the minimum necessary operating standards for PSCs and armed contractors seeking to support US military operations. These would include:

  1. Minimum hiring and vetting standards
  2. Minimum pre-deployment training requirements
  3. Make and model of weapons (western not eastern-bloc)
  4. Registration of weapons
  5. Rules of Engagement (ROE)
  6. Minimum uniform and visual identification standards
  7. Radio Communications systems and procedures
  8. Company registration with PCO, ROC and LMCC
  9. Prior notification of the TOC of all movements within their AOR
  10. Positioning of Liaison Officers (LO)
  11. etc

Once these procedures and mechanisms have been formalized at the doctrinal level, all BCTs and units would receive pre-deployment briefs and training on the role of PSCs in the battle space and essential information necessary for interoperability – particularly identification and communications.

Conclusion

Because of the military’s need to focus on the primary missions of fighting and winning wars, combating armed insurgency, and counter terrorism, civilian security contractors have become an integral part of stability and reconstruction operations. This is true in OEF and OIF and will continue into the foreseeable future in areas such as Sudan and the Congo. As such, PSCs and armed contractors need to be written into the operational plans and briefs. Just as the Situation paragraph in a five paragraph brief or OPORD has lines for Friendly Forces and Enemy Forces, a line needs to be added for Contractors in the Battle Space. In this way, every unit commander from the brigade down to the squad level will know to address the issues relevant to these armed contractors supporting DOD S&R and SSR operations.

Without security there will be no reconstruction; and without reconstruction there will be no peace. Security sector reform and police training are also critical to stabilization. Since all these functions are now handled by DOD or DOS contractors, they need to be written into training and doctrine at all levels.

Since most security contractors are former military, many with 10-20+ years of service, retiring as senior NCOs, warrant officers or officers, it should not be too challenging to create a matrix for interoperability between the active military and civilian contractors. IPOA, STTU, Operational Studies and other contractors stand ready to assist the DoD in developing the minimum operating standards necessary for safer, more efficient operations in future conflict and post-conflict environments.

END

Concurrent with his duties at Operational Studies, Mark Lonsdale was the US Director of Operations for a major multi-national security contractor actively involved in security and reconstruction operations in Iraq and Afghanistan. Lonsdale has also served as a member of the IPOA Standards Committee, is a DoD contractor, and a US military advisor involved in pre-deployment advisory and training of Special Forces and intelligence personnel.

Lonsdale Kandahar FOB Scorpion

Posted in Uncategorized | Leave a comment

Convoy Security in a Semi-permissive War Zone (Iraq & Afghanistan)

The following paper is based on the author’s observations and experience in Afghanistan and Iraq as a military advisor and DoD security contractor from 2002 through 2006, while staying abreast of current operations and incidents through 2007.



By Mark V. Lonsdale, Director – Operational Studies

 Copyright © 2007 / 2017

UNDERSTANDING THE PROBLEM

With approximately 160,000 US troops committed to Operation Iraqi Freedom (OIF), and an even larger number of civilian contractors (estimated at 180,000+), the demand for logistical support is massive. While some military supplies are flown in to US controlled air bases, the vast majority comes by ship, and then overland by truck. On any given day, thousands of tons of essential food, fuel, ammunition, reconstruction materials, and support equipment are on the road and on the move in Iraq and Afghanistan.

In Afghanistan, one of the main supply routes (MSR) is from Quetta, Pakistan westward into Kandahar and north to Kabul through some of the most dangerous real estate in that region. Convoys are also moving in and out of Kabul to support a myriad of reconstruction projects and military bases in the far flung reaches of the rural and border areas.

In Iraq, one of the main supply routes comes out of Kuwait, north through An Nasiryah to Baghdad, and from there further north up to Kirkuk and Mosul. Apart from the military’s voracious appetite for fuel and ammunition, the numerous forward operating bases (FOB) must be kept supplied with everything from food and drink to rolls of toilet paper and batteries. The base exchanges must also be kept supplied with all the modern conveniences and luxury items that US military personnel have come to expect – candy, cookies, magazines, souvenirs, toiletries, CDs, and the latest in electronic cameras, laptops, I-pods, and DVD players.

In addition to official military and KBR movements, there are hundreds of additional convoy operations requiring thousands of trucks to support the civilian reconstruction efforts. While most reconstruction projects are Department of Defense (DoD) or Department of State (DoS) funded, the actual projects are run by major US corporations. To further complicate matters, these major prime contractors will utilize a host of sub-contractors who in turn sub-contract smaller construction and support companies to fulfill various components of the prime contract – all of whom are moving on wheels and on very dangerous roads.

These convoys loaded with vital supplies are the very life-blood of the military and the reconstruction effort. They are also large, relatively slow moving targets for the Iraqi insurgents, al-Qaeda terrorists, and local criminals.  Where protective security details (PSD) protecting diplomats and businessmen operate primarily in economic centers close to military bases, convoy escort teams (CET) often find themselves hundreds of miles from city centers and very exposed. Fortunately, the insurgents are also very much out in the open in these areas making them easier to spot and kill.

This brings us to the current situation on the ground which is quite unique in the history of post-conflict occupation and counter insurgency warfare. Even though lessons can be learned from other models such as World War II, Vietnam, Bosnia and Kosovo, the military, reconstruction companies, and security providers are now confronted with a number of quite unique problems.

For one, security providers have been obligated to provide security in what could be considered an active war zone. The missions that security providers are being tasked with in Iraq and Afghanistan were traditionally handled by the military with armored vehicles and heavy weapons supported by quick reaction forces (QRF) and close air support (CAS). Further more, as major corporations compete for the lucrative multi-billion dollar contracts to rebuild Iraq and Afghanistan, the sheer volume of security providers running around in armored SUVs is unprecedented in the history of post-war reconstruction efforts.

To meet the government, military and private sector’s growing demands for security services, security providers have been forced to violate the most basic tenants of security by establishing predictable patterns on high profile movements. On any given day moving on the MSRs, dozens of PSDs and CETs are channeled into predictable choke-points, at the International Zone (but still referred to as the Green Zone), Camp Victory, the Baghdad International Airport (BIAP), Abu Ghuraib warehouse complex, Taji Military Training Camp (co-located with Camp Cooke logistics base), Balad and Anaconda to the north, and on all the major arteries to points further a field such as Al Asad air base out west, in the heart of insurgent dominated Al Anbar province.

This level of predictability creates numerous targets of opportunity for the insurgents and a situation that would under normal circumstances be considered unacceptable in the security industry.  One of the first rules of security states that if intelligence indicates that a location is dangerous, simply avoid it. Unfortunately this is not possible in Iraq or Afghanistan. Logistical support must be maintained and supplies delivered, so running convoys on the MSRs becomes an unavoidable hazard.

Looking at the classic “Military Model” for convoy escort the army utilizes lorries and tractor-trailer units designed for military use, driven by trained soldiers and Marines, supported by multiple armored escort vehicles armed with heavy machineguns (7.62mm and .50 caliber) and MK19 40mm grenade launchers. The military also has the option of shutting down major highways and creating exclusion zones, or saturating a high-risk area with additional fighting patrols or calling in close air support.

However, many of these tactical options are not available to the contractor or private security provider. While KBR’s logistic convoys carrying critical military supplies are protected by armored military escort units, this protection is not extended to the thousands of other convoy movements traveling on the same roads and under the same conditions.  Many reconstruction convoys of 30 to 100 trucks run with little more than three to five lightly armored SUVs and a handful of armed civilian contractors.

THE SITUATION ON THE GROUND

Iraq and Afghanistan are definitely not permissive environments but they can be considered semi-permissive environments in that a significant amount of productive work can be achieved, even though contractors do not have total freedom of movement. Civilian contractors know that it is unwise to leave the security of the military bases or secured compounds such as the Green Zone, Palestine and Sheraton Hotels, and Camp Victory without an armed escort and in armored vehicles.

Even with PSDs, elevated threat levels will periodically make movement between specific locations inadvisable. Sound intelligence and an understanding of the current situation should always drive the operational side of the security effort and ground movements. However the situation on the ground can change rapidly making it all but impossible to stay abreast of emerging threats.

Very few companies have the OP-CON or communications infra-structure to identify changes in the threat or traffic choke points though out Iraq or Afghanistan; and then get that time-sensitive information out to their PSDs and CETs on the fly.

After the fall of Baghdad, when US troops were welcomed by the Iraqi people, a massive reconstruction process was launched by the DoD, DoS, USAID, and Coalition Provisional Authority (CPA), support by several major US construction entities.  This was done under the assumption that the peace would hold and the Iraqis would become willing participants in the reconstruction process.

However, as a direct result of civil unrest, ethnic and religious rivalry, and rampant criminal activity, the peace did not last and US military personnel, coalition troops, and foreign contractors became the targets of insurgent and criminal attacks. These attacks were backed by former Saddam loyalists, Fedayeen guerrillas and foreign jihadis; and soon spread to acts of intimidation and violence targeted at Iraqi civilians supporting the reconstruction effort.

The early attacks ranged from direct small arms fire (SAF), to indirect fire rocket and mortar attacks, to roadside IEDs. This then escalated to vehicle-borne car and truck bombs (VBIEDs) driven by suicidal fanatics. Many of the less effective attacks were perpetrated by young, unemployed men paid by former Ba’ath Party Saddam loyalists. The more sophisticated military-type attacks were executed by guerrilla-trained Fedayeen Saddam and foreign Jihadis financed and trained by Wahabbi and Al Qaeda type movements.

As of late March 2004, spurred by the killing and mutilation of four Blackwater contract security personnel in Falloujah, the violence in Iraq rose to a new level. Military and civilian contractors came under frequent attack from not only Saddam loyalists and insurgents, but also radicalized Shi’a militias and religious fundamentalists.

The FOB where the author was working as a DoD security contractor came under 220+ mortar and rocket attacks between March and June 2004, and several Iraqi workers were killed coming to work or driving home.

As the US Marines prepared to enter Falloujah in early April, insurgents launched pre-emptive strikes against US forces in the neighboring town of Ramadi; and simultaneously, the Shi’a militias loyal to Muqtada al-Sadr (aka Mooky) initiated attacks from Sadr City in eastern Baghdad all the way south to Najaf and Karbala. This situation continued to deteriorate as Sadr offered rewards for the killing or capture of coalition soldiers.

THE CHALLENGES FOR CONVOY ESCORT TEAMS (CET)

Before attempting to develop convoy protection procedures or attack counter-measures, it is important to first appreciate the challenges involved in running convoy operations in semi-permissive war zones.

Challenges include:

  1. Large slow moving convoys
  2. Unarmored trucks, lorries, tractor-trailer units and fuel tankers
  3. Poorly trained drivers often from third world countries (US KBR drivers excluded)
  4. Movement on highways and major supply routes (MSR)
  5. Predictable points of origin in Kuwait, Turkey, Jordan, Pakistan, Iran, etc
  6. Convoys channeled into known military bases, logistic distribution points, warehouse complexes, and reconstruction projects
  7. Wide ranging movement in isolated areas
  8. Limited access to military support or Quick Reaction Forces (QRF)
  9. Thriving criminal activity in which the drivers may be complicit
  10. Drivers communicating with or sympathetic to the insurgents
  11. Well established insurgent attack methodologies
  12. Poor road conditions and traffic jams
  13. Military activity in the AO restricting convoy movements
  14. Being fired upon by US and coalition forces
  15. Security providers and CET teams of marginal capability
  16. An over dependence on local nationals (LN) and third country nationals (TCN) for convoy escort duty.
  17. Poor communications networks

These are in addition to the more mundane administrative challenges:

  1. Drivers who do not speak English
  2. Drivers lacking sufficient documentation
  3. Delays crossing border checkpoints
  4. Corrupt customs officials
  5. Logistics companies making errors in paper work
  6. Vehicles running out of fuel, breaking down or becoming lost
  7. Drivers refusing to drive along specific routes
  8. Departure or turn around delayed by loading logistics
  9. Delays at military vehicle checkpoints (VCP)
  10. The inability of LNs and TCNs to enter US military bases
  11. Security providers lacking the correct badges (CAC, MNF-I, ISAF)
  12. Uncooperative bureaucrats at all levels of the supply chain

The only light in all this gloom was the establishment of Logistics Movement Coordination Center (LMCC) in Baghdad, and ISAF cooperation in Afghanistan.

INSURGENT ATTACK METHODOLOGY

The more dangers regions of Iraq and Afghanistan have turned to classic counter-insurgency guerrilla warfare with relatively small numbers of insurgents and fundamentalists utilizing five primary methods of attack.

  1. Small arms fire (SAF) with rifles (AK47s, AKMs, AK74s) and light machineguns (RPK, RPD, PKM). These are usually hit and run type attacks or linear ambushes allowing the shooters to melt back into their neighborhoods.
  2. Attacks on buildings and vehicles with RPGs (rocket propelled grenades). Fortunately a significant percentage miss the target or fail to detonate.
  3. Mines, improvised explosive devices (IEDs) and roadside booby-traps. Definitely one of the biggest problems in Iraq with the shrapnel from improvised artillery shells proving to be devastating.
  4. Indirect fire mortar and rocket attacks, often from 3 – 5km with 60- 82mm mortars, but in some instances from distances of up to 18km with old 122 mm and 127mm rockets.
  5. Vehicle-borne improvised explosive devices (VBIED) driven by suicide bombers, frequently directed at military and police checkpoints or recruit depots but also at PSD and CET teams. A VBIED can also be the precursor for a SAF ambush.

Of these, the IEDs pose the greatest threat when moving about in vehicles, while mortar and rocket attacks pose the greatest risk to FOBs. Roadside IED attacks have become a depressingly routine part of life in Iraq with multiple attacks on various MSRs every day.

RPGs are also quite prolific in post-war Iraq so are often used in attacks on vehicles and convoys. One only has to look to CNN or FOX to see the effect of an RPG hit on a fuel tanker or truck. The RPG-7 is a reloadable, simple to operate, shoulder-fire weapon that can be loaded and fired by one man. The RPG launches an armored-piercing projectile with an effective range of 300 meters on moving targets, 500 meters on static targets, and has a burn-out range of just over 900 meters. Fortunately, the insurgents have not demonstrated any high degree of proficiency or accuracy with these weapons but they do occasionally score a hit with tragic consequences.

In addition to direct attacks, insurgents and fundamentalists have engaged in numerous kidnappings of Iraqi citizens, foreign coalition workers, soldiers and truck drivers. In some instances the victims have been killed; in some they have been released; and in one the victim was able to escape to safety.

INSURGENT TARGET SELECTION

Many of the attacks launched by both the insurgents and the fundamentalists are planned attacks but their victims are often random targets of opportunity. Although the terrorists’ greatest animosity is directed towards US and coalition occupation troops, the military presents a more difficult target to hit than the police and civilian population. This includes civilian convoys and private security contractors.

Attacks continue against the Green Zone, military convoys and military bases, which are usually considered hardened targets, but the most devastating attacks are launched against softer targets such as police stations, recruitment centers, marketplaces, government officials, government offices, NGO buildings, and convoys.

The chance of being attacked when moving between points in Baghdad or Kabul is as much a matter of chance as design. The same is true for any of the major MSRs that run through “Indian country.” IEDs are often placed and ambushes staged for the first or most suitable target of opportunity to come down the road. However, the two roads in Iraq that get hit with regularity are Route Irish between the Green Zone and BIAP, and Route Tampa, the MSR that runs from the Kuwait border north through Baghdad, then up through Balad, Samarra, Tikrit, Baiji and Mosul, then finally to the Turkish border at Zakuh. Large convoys also run south down the same route every day.  In Afghanistan, things get interesting when convoys push down through Ghazni and Zabul into Kandahar and Helmand province.

The obvious problem for the convoys and CETs is that once they leave their point of origin, it does not take a rocket scientist to calculate where and when they will be passing any given point on the MSR. In addition, as a convoy passes through one area, an insurgent – what the Brits call a “dicker” – can call ahead to his cohorts waiting in ambush or preparing the IED.  To further compound the problem of predictability, a convoy running out to make a delivery in the morning, will often return down the same route in the late afternoon or evening.

ATTACK ANALYSIS

The attack on the Blackwater CET in March 2004 was a rude awakening for many security contractors, not just Blackwater management. In this instance the CET was reportedly sent out under manned, under gunned, in soft-skinned vehicles, and without a route reconnaissance team. (This incident is still under investigation and litigation) The Marine commander responsible for this military area of operation (AO) was also unaware of the contractors’ movement and route so was not well positioned to mount a QRF. The results were a tragic loss of life (one a close friend of the author) and an immediate re-evaluation of all PSD / CET SOPs and movements.

In this case there is no indication that the team or their convoy was selectively targeted by the insurgents. It was in all likelihood a case of the attackers setting an ambush in an ideal location, such as a chokepoint, congested area, checkpoint or overpass, and this team unfortunately driving into the kill zone.  In this and several other cases, it can be noted that the modified civilian SUVs used for escort are simply not up to the level of concentrated fire or method of attack they are exposed to.  It could be argued that the Blackwater team was slaughtered because the other vehicles in the convoy were unable to come to their assistance, but in all likelihood they were killed by the initial burst of fire or overpressure from an RPG. (Blackwater has since developed a purpose-built armored vehicle called the Grizzly)

Other companies have been hit even harder than Blackwater losing over a dozen security contractors and drivers in each ambush. However, after all such cases, the PSCs have continued to run operations in the face of an on-going insurgent campaign. Even if the location and timing of a specific attack is unknown, the threat has been identified and accepted, as is the case with all CET operations in Iraq. So where standard security doctrine is based on risk avoidance, Iraq and Afghanistan have driven security providers into a policy of risk acceptance. For some private security companies (PSC) the level of acceptable risk is higher than for others and has become known euphemistically as “pain tolerance”.

This then raises the question or whether the current security tactics, procedures and equipment are sufficient to meet the identified and accepted threat. Obviously even armored SUVs are not designed to survive a direct coordinated attack with military-grade weaponry.

So with risk acceptance comes the obligation by the security providers to supply their PSDs, CETs and clients with the best of service and equipment at all levels to meet the identified threat. Since the threat is military-grade attacks, the defensive measures must be equally robust. The ever changing nature of the threat may also require an equally flexible approach to tactics and methodology.

TACTICAL METHODOLOGY

In addition to the military model, there are basically three tactical philosophies or methodologies at play with security companies currently running convoy escort operations in Iraq and Afghanistan.

  1. In the early days of reconstruction in Iraq – late 2003 thru early 2004 – many PSCs were running ultra-low key “Low Profile model” CETs utilizing locally purchased SUVs, soft-skinned vehicles, and even taxis driven by local drivers. It must be understood that this approach was not just a tactical decision but also a fiscal one. Many of these new start-up companies simply did not have the financial resource to invest in a fleet of new armored vehicles and gun trucks at $150,000 a piece so were running “guerrilla security operations”. However, while benefiting from very low profile movements in unobtrusive vehicles on PSD operations around Baghdad and Kabul, they were less successful at high profile convoy operations.

2. At the other end of the spectrum are the high-profile movements with multiple armored SUVs and gun trucks, usually large American Chevy Suburbans, Ford Expeditions and Excursions, or heavy duty pick-up trucks. The drivers and shooters are all fully kitted with visible plate body armor, load-bearing equipment, additional ammunition, FBG stun grenades, and automatic weapons – mostly M4s, AK47s or SAWs (squad automatic weapons). This is the “US Model” that is common with US governmental and military PSDs and CETs but quickly became the norm for their British counterparts.  The tactical advantage that these teams derive from this approach is not only overwhelming firepower but also a certain deterrent factor. This would be the case where one or two insurgents may opt not to attack a large “fighting formation” when they can wait for an easier and softer target.

3. The third methodology is the “Corporate Model” which falls between these first two. Security companies whose core competence was in western executive protection and risk management were employing a somewhat low-profile approach while still driving identifiable up-armored fleet SUVs. The PSDs and CETs were armed but not obviously so and the companies’ weapons policies were more restrictive. Pistols and rifles were kept concealed and security personnel wore lighter armor and no visible load-bearing vests. This equated to less ammunition, less fighting capability, but a more “politically correct” image. This approach could be considered “semi-tactical”. Unfortunately it has neither the deterrence of full para-military firepower nor the safety of totally “low profile” movements.

4. The forth approach that was not being utilized by private security in 2004 through 2006 was the “Military Model” which would require up-armored Humvees, light armored vehicles (LAVs), or APCs equipped with crew-served weapons systems such as the GPMG, M240G, MK19 and the M2 BMG .50 caliber. This model has been used by private security in Afghanistan and has been considered by several security contractors in Iraq – particularly for convoy escort duty in remote areas. This is the only model that offers immediate and aggressive counter-force and suppressive fire for an ambush break-contact drill.

CORPORATE PHILOSOPHY

The antithesis of good tactics and sound military war fighting doctrine would be corporate image and social responsibility. Western security companies tend to cultivate a corporate image of impeccable professionalism and expertise in the fields of high-end risk management and international security. They have also gone to great lengths to distance themselves from any association with private military corporations (PMCs) and para-military operations such as Executive Outcome (EO) and Sandline, even though both demonstrated considerable capability in support of stabilization efforts in Africa.

British companies in particular established themselves as the foremost respected organizations in the international security field, earning this reputation through detailed and professional intelligence collection, threat analysis and identification, and risk avoidance.  Unfortunately elevated risk is a part of daily life in Iraq and Afghanistan that realistically cannot be avoided, only minimized.

If security companies were to be true to the concept of risk avoidance, they would simply advise their clients not to come to Iraq. But in the current context, reconstruction operations have moved past that point or option. A few PSCs brought to Iraq very professional operations with first-class personnel and equipment, along with communications, intelligence and logistical support. But was there room for improvement? The answer must always be most definitely! As the situation and threats change on the ground, security equipment and procedures must also change.

The CET model that was being run in early 2004, for example, of two or three vehicles with a driver and a shooter in each was grossly inadequate falling far short of the requirements to secure even a small convoy of even 10 trucks. Yet in 2005 PSCs were still running CETs that were little more than a vehicle in front to lead the way and a follow vehicle to keep the convoy closed up or spot any break-downs.

A number of PSCs also applied the tried and proven methodologies for corporate security in a permissive environment to security operations in a more high threat semi-permissive war zone.  They followed the time-proven security doctrine of intelligence collection and risk analysis, and when the threat indicated, shutting down all movements for the safety of the client or convoy.

While this philosophy and methodology cannot be faulted from a risk management standpoint, especially where the client absolutely does not want their employees or drivers injured, kidnapped or killed. However, it became evident that several contractors and clients working in Iraq were willing to raise their threshold for risk (pain tolerance) to have more freedom of movement and in an effort to become more productive.

In some cases, it has been noted by reconstruction contractors that a risk avoidance policy and refusal to run PSDs and CETs when the threat level warrants, has been considered a hindrance to the client’s work output and movements. However, it must also be noted that these same clients may be somewhat uninformed as to the actual threat and dynamics at play. They focus only on their immediate needs without considering the very real risks that intelligence may have identified.

It has been observed that the construction clients and logistics companies appeared not to care how risky it was to make a convoy run. Their focus was on their contractual obligations to deliver goods with less regard for the trucks or drivers. Their thinking was more fiscal which clouded the decision process and flew contrary to sound security thinking. Never-the-less, they were willing to go with any security provider who was willing to make the run, even if that provider did not have the intelligence and communications resources of a professional PSC – and even if that security provider’s CETs were enjoying a run of success derived more from luck than planning.

WORKING IN IRAQ & AFGHANISTAN

Where most security providers accept the risk of movements in this current high threat environment, other PSCs continue to employ their time-honored philosophy of risk avoidance. But again, it must be noted that risk avoidance in an insurgent war zone is all but impossible if movements are designed to support an acceptable level of productive work for the clients.

PSCs may lose ground with clients when they shut down CET movements while other provider’s make successful runs at the same time and on the same MSRs. Granted, a big part of a successful run is luck, especially when the movement is made oblivious to elevated threat indicators and lacking sound intelligence. Since statistically the probability of an attack on a specific convoy, on any specific road, at any specific time, is low, these more aggressive teams end up earning a reputation as being gutsy not foolhardy (in the eyes of the client).

However, the laws of probability can also work against a security provider. The bigger the footprint, the more numerous the convoys, and the greater the number of CET runs, the higher the probability that one of these teams will be unlucky. This is not a product of poor planning or bad tactics, but simply bad luck when a convoy drives into an opportunistic ambush or IED attack.

RISK ACCEPTANCE

Instead of risk avoidance, the working model for other companies in Iraq and Afghanistan seems to be risk acceptance & risk identification, and then an attempt to adapt their tactics to suit the mission. This is done by either venturing out in full battle mode with the most powerful vehicles and weapons available, or by going low profile and trying to slip through unnoticed. Both these tactics have obvious strengths and weaknesses.

Even the best armored SUV is still vulnerable to RPG and IED attacks, but the weight and power may carry them thru the kill zone to get the vehicle off the X. But this does not help the large, unarmored trucks and unprotected drivers in the convoy. Heavily armored SUVs also deny the opportunity for return fire or aggressive counter-force except for ramming – thus the birth of the armored gun truck for CET operations. With an exposed heavy machinegun in an armored box in the back of the pick-up, the gunner can now engage 360 degrees and has an elevated position of advantage (even though still exposed to hostile fire)

Those traveling in low profile mode are extremely vulnerable if their cover is blown or they are caught in heavy traffic. The heavy low-slung sedans, while they may handle better on the open road, are just not suited to curb jumping, ramming or going off-road in exigent circumstance. The armor in local vehicles is also of unknown origin and quality.

On the personnel side, going in with a CET that is kitted-up for a fight with full body armor,  state-of-the-art weapons, multiple accessible magazines, and stun grenades, is not only preferable to the shooters, it also gives the convoy drivers a greater sense of security. This “look and feeling” of security cannot be underestimated when dealing with a clients’ perception and sense of well being. Some clients have been sold on the heavy “US model” that they have seen around town with companies such as Blackwater, and there are times when this model is the more preferred option.

Again, and at the other end of the spectrum, utilizing local Iraqi drivers and shooters has both benefits and risks. The benefits being that they can drive around without drawing attention, they know the streets, can run route reconnaissance, and may be less likely to be attacked. The risks lie in their basic lack of training and experience and the potential for betrayal. If this model is to be used, then thorough vetting and training is essential.

There has also been observed considerable disparity in the kit issued by various PSCs to their CET security personnel. Where LNs or TCNs may be issued an old AK47 and a few magazines, more professional western teams will have state-of-the-art level IV body armor, modern M4 weapons, SAWs, and load-bearing vests chocked with magazines, radios, GPS, and grenades.

Training is another issue. It would be unheard of in the military special operations community to send operators into a hostile environment without the opportunity to zero and become familiar with their personal weapons; or to be told to procure weapons locally. When some PSC personnel rotate back in country, they may often be issued different weapons to the ones they carried on their previous deployment. This highlights the need for a professional approach to weapons and equipment, and the need for permanent range facilities for formal and informal weekly test-firing, zeroing and training.

TACTICAL CONSIDERATIONS & SOLUTIONS

One of the fundamental principals of tactical operations is flexibility – and applies equally to CET security operations. This includes flexibility in equipment load, flexibility in manning, flexibility in mobility, flexibility in tactics, and most important of all, flexibility in thinking. However, some PSCs in Iraq appear to be following one institutionalized doctrinal approach to security operations in general. If this approach or model is based on corporate security operations in a permissive environment, it is definitely not the best model for Iraq and Afghanistan.

After the first attacks in late 2003, PSC personnel were quick to realize that 9mm primary weapons such as the MP5 were inadequate in an open ambush scenario; a lesson that had to be re-learned from the SAS Regiment’s experience in Northern Ireland. This necessitated the adoption of AK47s which was a significant departure from the western corporate image. Similarly, other aspects of the low-key corporate security model were found to be not applicable to operations in Iraq.

A good example of this was where most of the security providers were running a minimum of 5-vehicle CETs, others were still running 2-vehicle movements. A 2-vehicle CET would be the minimum in any routine operation in the US or Europe, but Iraq is considerably more risky than routine. Having two or three additional heavily armed vehicles is essential for fighting, blocking and ramming, to shield the trucks and drivers, to supply cover-fire for a break-contact drill, or a cross-deck hot extraction.

The best argument against 2 or 3-vehicle CET operations is where one CET vehicle is disabled in an ambush. Do the remaining CET vehicles come to the assistance of the disabled vehicle or is their primary mission to shepherd the convoy out of the kill zone. There needs to be a sufficient number of CET vehicles to do both. At least one can assist the disabled vehicle by laying down cover-fire while pushing, towing or cross-decking; while the other three can keep the convoy moving off the X.

PSCs need to adopt a tactical and flexible approach to CET operations to best match the changing threat and to meet the needs of the client. Where in some circumstance a low profile 5-vehicle CET may be appropriate, in others, a 6 or 10-vehicle CET with full war-fighting load and gun trucks may be the wiser choice.

This comes back to one of the most basic principles of tactical planning – matching the force to the mission. If the force is too big it becomes slow and vulnerable; but if it is too small it is not able to defend itself or even break contact with a determined enemy.

There are a number of factors that should be considered in the manning for convoy escort operations, to include:

  1. Number of trucks, lorries & overall length of convoy (With a minimal 100-meter spacing a 30-truck convoy with CETs will extend over two miles)
  2. Relative value of the load (Do the bad guys want the contraband, particularly loads such as fuel or cigarettes?)
  3. Vulnerability of the loads (example: fuel tankers)
  4. Length of the planned movement (Two hours or two days)
  5. Experience of the truck drivers (can they drive fast and stay on route?)
  6. Prior corruption issues with drivers
  7. Armament of the CET vehicles (Heavier machineguns can cover larger arcs of fire and longer ranges)
  8. Experience of the CET security personnel (Less experienced teams should be augmented by more vehicles and operators)
  9. Time of day and predictability of the convoy run
  10. Frequency and timing of attacks on specific MSRs (Routes Irish and Tampa)
  11. Prior threats or attacks directed against a specific company’s trucks
  12. Inter-tribal rivalry derived from running trucks and drivers from one region through a rival group’s area
  13. Road conditions and choke points
  14. Proximity to FOBs and availability of a military QRF in a timely manner
  15. CASEVAC options
  16. Current Intelligence & Threat Assessments

In implementing this type of approach, the protection package may be flexible, but the basic equipment, weapons and contact drills remain standardized. However, when stepping up to this next level of CET operations, it may require additional in-country training to bring all the individual operators up to speed. Major US contractors are running their PSD personnel through theater-specific training before deploying to Iraq. The British companies are also making their in-country training more robust to match the elevated threats. However, few run training for CET teams since it was not a contract requirement.

There is a collateral advantage to more robust CET operations and that is confidence for the actual team members. Virtually everyone working PSD and CET is former military or SWAT so has had the experience of kitting up in full war-fighting load for an operation. There is a routine and ritual that brings the team together and creates the right mindset for the impending risky operation. This same ritual and behavior pattern has been observed with several PSD/CET teams in Iraq as they kit up for a hazardous run. It has also been observed that the clients and truck drivers are not only fascinated by this pre-deployment ritual, they appear to gain assurance from knowing they are traveling under the protection of professional war-fighters and not just bodyguards.

PRACTICAL & FISCAL LIMITATIONS

There is however a number of practical and fiscal hurdles that needs to be negotiated when moving to more flexible force packaging. The first practical consideration is the need for a tactical operations center (TOC) that is above and beyond a routine business communication and coordination center. A CET TOC would require that the operations manager have a number of resources on-hand or on stand-by for deployment. Only by having these people and vehicles on immediate stand-by can the operations manager match the security to the threat in an often rapidly changing environment. This would require some form of ready room or holding area from which CET teams and QRFs could be launched.

On the fiscal level, this more flexible force packaging creates problems in pricing and billing the client. The cost of a specific convoy movement would be unpredictable since the CET security package would be selected just before the operation based on best intelligence and the operations manager’s judgment. In some cases the client would receive a 5-vehicle CET with 10 operators, but on others, an 8-vehicle CET with 24 operators (usually a mix of internationals, TCNs and LNs).

So even though this may be the optimum method it may be impractical for fiscally conservative clients unless a contract or memorandum of understanding (MOU) is in place that allows the PSC operations manager to ratchet up the security package when specific conditions were in place. The most basic of these is a ratio of convoy trucks to CET vehicles, for example one in five – for every 5 lorries there is a CET vehicle inbedded in the convoy. So as the client adds trucks, the PSC is authorized to add CET teams.

AIR OPERATIONS

Another option that is being under utilized in Iraq and Afghanistan is helicopter supported operations. In both the construction and the security industries in the United States and other countries, helicopters have become a regular and daily part of operations. Clients landing at major airports are routinely moved to corporate centers or job sites by helicopter, by-passing both traffic congestion and ground threats. Aircraft are also used for site surveys and pipeline inspections.

Helicopters or fixed wing aircraft could be used in Iraq and Afghanistan for route reconnaissance, traffic reports, aerial surveillance of high-risk areas, as gun ships in the event of an attack, and CASEVAC in the aftermath. But again, this creates issues with cost, maintenance and the risks associated with flying in military airspace – all beyond the scope of this paper.

CONCLUSION

The threat levels in Iraq, and to a lesser extent in Afghanistan, have increased considerably since 2004, and can be expected to continue to increase in the immediate future. Even though the latest surge appears to be having some traction in Baghdad, Iraq and Afghanistan will not become safe permissive environments for foreign contractors any time soon. While some contractors enjoy the security of the Green Zone and US military FOBs, the convoy operators are doomed to be out on the highways presenting very attractive targets to the insurgents.

While STTU and Operational Studies have developed a number of effective tactics, techniques, and procedures for convoy escort and PSD operations in high risk environments, they cannot be presented in this paper which will be circulated in open forum.  It is sufficient to say that professional convoy security is a combination of good intelligence, effective long range communications, well equipped personnel and vehicles, rigorous training, and an aggressive, rehearsed counter-force capability when all else fails. Reconstruction contractors, security providers and logistics companies should also ensure that their truck drivers have the necessary training and personal protective equipment (PPE) to maximize their survivability in the inevitable attacks.

– Mark V. Lonsdale

Mark-Lonsdale Iraq Saddam

Mark V. Lonsdale – Iraq, 2004



Copyright © OSG 2007

Posted in Afghanistan, Contractor Security, Convoy Escort, Iraq War, PSD, Uncategorized | Tagged , , , , , , , , , , , | Leave a comment

Rifle Calibers for F-TR and PRS Tactical Division – and Why .308 Winchester?

By Mark V. Lonsdale – STTU

Based on a number of questions from shooters hoping to get into F-Class Target Rifle (F-TR) of Precision Rifle shooting, there is obviously some confusion floating around concerning rifles and calibers. One individual, who was shooting a 6.5 Creedmoor, thought that because he was on a  bi-pod, not a tripod, he would be in F-TR. Not so. Another was tossing up between .243 Win. and 6.5, because that’s what the local gun shop “expert” told him. Again, a case of so called “experts” not reading the rules or being competitive shooters. If a shooter wants to learn about any form of competition, go to a local match and talk to the better informed serious shooters.

F-TR mid-range (600 yards) and PRS are both long range shooting events where a new shooter can have fun and gain a lot of experience with a relatively inexpensive rig (less than $1,500). But as with any precision shooting sport, if a shooter wants to do well at the national level, and is willing to put in the time and practice, then he or she is still going to need a custom purpose-built rifle with high-end optics. But keep in mind that the amount an aspiring champion invests in the rifle(s) is a fraction of what they will spend on practice ammunition, reloading equipment, travel to matches and entry fees.  And I say rifles, plural, because F-TR, PRS Bolt Gun, and PRS Gas Gun all have different features and requirements.

F-TR and PRS Tactical were created so that law enforcement and military shooters could use their issued rifles to compete – therefore only .308 Winchester or 5.56 NATO / .223 Remington. Those are the only two calibers a shooter can shoot in F-TR or PRS Tactical. The additional requirements for FT-R include a bi-bod and a rear bag, but no tripods or muzzle brakes. Rounds are loaded singly in F-Class so a magazine is not required.

The top F-TR shooters are running custom built single shot bolt actions (Kelbly, Panda), heavy 30″+ barrels (Bartlein, Krieger), custom stocks such as the McMillan XiT, light target triggers (Timney, Jewell), high-end optics (Leupold, Night Force), and wide, purpose-built bi-pods (Phoenix Precision).  So even in F-TR, an agency sniper rifle with a 22″ barrel will be up against an $8,000 custom F-TR rifle. But like me, you can still go out with your sniper rifle or varmint rifle, with factory Federal Match ammo, and gain some good experience reading wind at the mid-range 600 yard matches, plus have a great day shooting alongside like-minded individuals.

Derek Rodgers Rifle

Custom built F-TR rifle belonging to one of the US Team



Rem700 LS-Mark8 ELR

Sniper rifle built on a Rem 700 action with a 23″ Krieger barrel, McMillan M40A3 stock,                      and Leupold Mark 8 Scope, shooting factory Federal Gold Medal Match                               168 & 175 grain SMKs

For PRS Tactical division, again, the rifle must be .308 Winchester or 5.56 NATO / .223 Remington. The heaviest projectile permitted in .308 Win. is 178 grains launched at no more than 2,800 fps; and for .223 Rem. it is 77 grains at no more than 3,000 fps. Rounds are loaded from the magazine in PRS, so detachable magazines are a necessity, and muzzle brakes are permitted. It is also not unusual to shoot over 100 rounds in a PRS match so an excellent day or two’s experience at multiple ranges.

McMillan A3-5 Adjustable

Rem 700 .308 Win. action with McMillan A3-5 adjustable stock, Badger Ordnance trigger guard/detachable magazine, topped with a Leupold 4.5-14x scope.

These same limitations for bullet weight and muzzle velocity extend to PRS Light Gas Gun division (.223 Rem) and Heavy Gas Gun division (.308 Win.)  There is also a Bolt Gun Production division in PRS where the rifle and scope combined cannot exceed $4,000. See precisionshootingseries.com for all the rules.

END

Posted in .223 Remington, .308 Winchester, F-TR, Firearms, Leupold, Long Range Shooting, McMillan Stocks, Precision Shooting, PRS, Sniper | Tagged , , , , , , , , , , | 1 Comment

ROBAR Firearms NP3 Finish

By Mark V. Lonsdale – STTU

Over the years I have tried several finishes on my handguns and rifles, to include conventional gun blue, Pakerizing, black phosphate, hard chrome, electroless  nickel plating, Roguard and NP3. Of all of these, NP3 has truly impressed me with its lubricity and resistance to corrosion.

When I first had Robar of Phoenix, AZ, NP3 one of my carry handguns, it was because I was working in a salt water environment and my blued guns were literally rusting overnight. I also had a problem that when I was training in the desert, the sweat running down my side was running into the holster with the same result – a thin film of red rust by morning.

Sig228 Carry9mm

Every day carry (EDC) SIG P228 9mm with NP3 finish.

Ever since I began using NP3 in the early 1990s, I have no longer had this problem, and I still work in hot, humid environments. I also had Robar NP3 the bolts of my sniper rifles to slick up the actions.

SR90 300 Fixed M3

Bolt of my SR90 300 Win Mag with NP3 finish. Definitely slicks up the action and makes the bolt easier to clean.

Robar-7mmMag

Robar 7mm Mag sniper rifle with NP3 bolt and Roguard barrel and action

From the Robar webpage:

Robar’s® NP3® finish is an electroless nickel-based finish for steel, stainless steel and aluminum alloys that co-deposits sub-micron particles of PTFE (polytetrafluoroethylene), otherwise known as Teflon™, with electroless nickel.

NP3® metal finish offers many benefits. NP3® permits firing for longer periods of time between cleaning, dirt and powder residue have no wet or oily surface to cling to. When cleaning is required, the effort needed is minimal – usually requiring only a soft cloth. NP3® is very corrosion resistant. It provides a high lubricity and low friction co-efficient, greatly increasing the life expectancy of a firearm due to reduced friction wear. NP3® is a satin gray, non-reflective color ideal for all firearms.

NP3® can be plated to all internal parts giving smoothness to the action not found with any other coating. In cases where the NP3® has been perforated, the corrosion shows no tendency to spread or migrate under the coating. NP3® also carries a lifetime warranty.

END



Posted in Firearms, Sniper, Weapons Evaluations | Tagged , , , , , , , , , , | Leave a comment

Federal Gold Medal Berger 185 grain Juggernauts

By Mark V. Lonsdale – STTU

For shooters who do not have the time or inclination to hand load, Federal’s Match Grade ammunition has long been the staple diet for many of those shooters. Back in the 1980’s, when Federal Match ammo came in red and white boxes, the 168 grain Sierra Match King (SMK) was first choice for our sniper training and the standard by which we judged all sniper ammunition. While its thin jacket and integrity through barricades was less than ideal, the accuracy and consistency was superb.

This has continued to today where we still use the Federal Gold Medal Match (GMM) 168 grain as out baseline standard for .308 Win. rifle evaluations. I have also been using the 168s for 600 yard competition shooting with no complaints.

Rem700 LS-Mark8 ELR

Tac Ops Lima 51 .308 Win. sniper rifle with Leupold Mark 8 scope

The introduction of the Federal GMM 175 grain SMK added another option to the game. We now test all rifles with both Federal GMM 168 and 175 grain  to see which one produces the better accuracy. The general recommendation has been that 1:12 twist barrels work well with the 168s, and 1:10 the 175s, but this is not a hard and fast rule. In some cases we have found 1:10 barrels that perform best with the 168s, but the 175s come into their own out past 600 yards when it comes to wind deflection.

Now we have a welcomed new addition to the Federal lineup — the Federal Premium Gold Medal Berger 185 grain Juggernaut, a Hybrid Open Tip Match (OTM) Boat Tail. We have just started evaluating this ammunition and getting excellent sub-MOA results at 100 yards. Next step is to run it out to 600 and 1,000 yards.

Fed Juggernauts

Federal Berger Juggernauts

Federal GM Berger 185 grain Juggernaut Hybrid OTM — group at 100 yards

080517 CS and Group

Federal Premium Berger 185 grain Juggernauts

END

Posted in .308 Winchester, Ammunition, Berger, F-TR, Federal Match, Firearms, Leupold, Long Range Shooting, McMillan Stocks, Precision Shooting, PRS, Sniper, Uncategorized | Tagged , , , , , , | 1 Comment

The Importance of Indexing Your Scope Mounts

By Mark V. Lonsdale, STTU Training Director

While running the return to zero evaluations in the previous article, we decided to try moving the mount further up the rail to see if it made a difference. We were using an American Defense UIC rifle with an AD cantilevered mount and a Leupold scope, so already knew that we were using high quality products that consistently returned to zero when removed and replaced.  But when we moved the mount forward on the rail, the result was a dramatic shift in point of impact.

VX 2-7 Mount Rail CU

In the image above you can see the placement of the scope mount at the forward edge of the received. The cantilever overhangs the fore-end handguard, but the actual mount is on the receiver. This is the same index reference we used for all the previous tests.

When the mount was moved one slot forward on the Picatinny rail (see arrow), the grouping at 100 yards moved 10 inches to the left. When moved back to the last slot on the receiver the group returned to zero. The reason for this is that the rail on the handguard is not integral to the receiver, so not machined in one monolithic piece. So while the rails appear to be in line, there is sufficient offset to throw the shots 10 inches to the left at 100 yards.

Lesson Learned: Always take note of exactly where your rings or one-piece mount are indexed on the receiver rail. Count the number of slots from the front or rear so that you can always reset the mounts to the same location.

MK 4 Leupold

Leupold Mark 4 mounted on an American Defense UIC Mod 2 .223 Wylde

END

Posted in Uncategorized | 1 Comment

American Defense Scope Mount Tests

By Mark V. Lonsdale, Training Director STTU

The goal for today’s testing was to evaluate whether AD scope mounts returned to zero after being removed and replaced. For the testing we used a Leupold VX-1 2-7X, 1″ tube, in the AD-Recon 1 STD mount, and a Leupold Mark 4 3.5-10X, 30mm tube, in the AD Delta-C 30 STD mount.

MK4 VX 2-7

Two Leupold scopes and AD mounts used in testing

After zeroing, the testing was done at 100 yards utilizing relatively inexpensive American Eagle 62 grain ammo; so the expectation was not sub-MOA groups, just consistent, repeatable combat accuracy. This could be defined as staying within a 3-inch circle at 100 yards. Future testing will be done with Federal Match ammo.

For the testing, we shot a 5-round group on one target with the Leupold VX-1 set on 7X, then changed scopes and mounts and shot a 5-round group on another target with the Mark 4 on 10X. We then replaced the VX scope and shot another 5-round group on the first target; followed by changing to the Mark 4 and shooting another 5-round group on that target. This was repeated three times.

MK4 ADM

                       Leupold Mark 4 mounted on the American Defense UIC Mod 2                                              with AD-Delta-C 30mm mount

In all cases the groups stayed within 0.5″-1.0″ of the previous groups and stayed well within the 3″ circle.

In addition to the positive cam locks and precision machined rails, one of the reasons that the American Defense mounts have a high level of return-ability can be attributed to the thick cross bolts that all but fill the slots in the rail (see pic below). Cheaper mounts use thinner bolts that allow the mount to move back and forth.

ADM QR Mount

Note the thickness of the cross bolts that contribute to a positive return-ability

END

Posted in Sniper, Weapons Evaluations | Tagged , , , , , , , , , , | Leave a comment

Afghanistan OEF 2001-2008

A few images from Northern Afghanistan with General Dostum



A few from Kandahar and Spin Boldak on the border with Pakistan

Posted in Afghanistan | Tagged , , , , , , , , , | Leave a comment

Iraq OIF 2004

A few images from Iraq during the Fallujah uprising

Clockwise: Bomb damage assessment from an incoming rocket; with Oscar PSD team; with General Paul Eaton, Combined Military Assistance Training Team (CMATT); morning briefing at Taji Military Camp, just north of Baghdad; with the only poster of Saddam not shot up by the Marines, at an Iraqi weapons development center.



Posted in Iraq War | Tagged , , , , , , , , | Leave a comment
